The SMD5206HS is a programmable single axis vector stepper drive with extended input/output.
- Voltage range from +24Vdc to +120Vdc (Power stage)
- Voltage +24Vdc (Logic stage)
- Current range from 0.1A to 6.0Arms , 8,5Apk
- Digital and Analogic I/O
- SSI absolute encoder input (optional)
- Open loop or Smart closed loop operation modes
- Position, velocity or torque control
- Stand-Alone positioning (programmable by the user)
- GUI configuration and visual programming
- Advanced diagnostic
